• Features bilateral centre welding zones
• PE100-RC material is resistant to the long-term expansion of cracks, scratching, and point-type loads. Point-type loads are especially common during the assembly of the pipelines using trenchless installation methods (for instance, as a result of friction against the stones that are present in the soil). In the case of a point-type load, tension, and plastic deformations are produced in the material, which may cause cracks in the internal surface.
• The result of applying electrofusion fittings is a solid and safe joint of pipe and any other elements belonging to the pipeline system. The electrofusion joint features excellent pressure resistance and tightness.

Electrofusion repair clamps are used in installations distributing gas, water and hyadrogen.

• Material: Polyethylene PE100-RC
• SDR class: 11
• Work pressure water systems: 16 [bar]
• Work pressure gas systems: 10 [bar]
• Work pressure hydrogen systems: 10 [bar]
• MRS: 10 [MPa]

Product dimensions
SDR11
D1 [mm]	A [mm]	C [mm]	Weight [kg]
63	115	109	0,33
75	117	123	0,38
90	128	138	0,50
110	128	162	0,56
125	128	170	0,63
140	127	180	0,54
160	130	230	0,81
180	130	239	0,87
200	169	239	1,36
225	169	239	1,38
250	169	265	1,47
280	169	267	1,46
315	169	290	1,57
