• PE100-RC material is resistant to the long-term expansion of cracks, scratching, and point-type loads. Point-type loads are especially common during the assembly of the pipelines using trenchless installation methods (for instance, as a result of friction against the stones that are present in the soil). In the case of a point-type load, tension, and plastic deformations are produced in the material, which may cause cracks in the internal surface.
• The result of applying electrofusion fittings is a solid and safe joint of pipe and any other elements belonging to the pipeline system. The electrofusion joint features excellent pressure resistance and tightness.

PE/brass transition fittings are used in installations distributing gas and water.

• Material - Polyethylene PE100-RC
• Work pressure water systems - 16 [bar]
• Work pressure gas systems - 10 [bar]
• Treads comply with EN10226-1

Product dimensions
External thread (male)
D1 x D2 [mm]	C [mm]	D3 [mm]	A [mm]	B [mm]	Weight [kg]
20 x ½"	22	34	126	81	0.15
25 x ¾"	28	35	129	85	0.14
32 x 1''	34	43	146	88	0.24
40 x 1''	34	52	160	94	0.30
40 x 1¼''	44	52	166	99	0.39
50 x 1¼''	49	62	186	108	0.51
63 x 2''	61	80	220	127	0.96
75 x 2½"	76	95	254	162	1.46
90 x 3''	88	112	288	180	2.17
110 x 4''	114	135	332	203	3.45
125 x 4''	114	151	348	225	3.99
Internal thread (female)
D1 x D2 [mm]	C [mm]	D3 [mm]	A [mm]	B [mm]	Weight [kg]
20 x ½"	26	34	114	81	0.14
25 x ¾"	32	35	116	85	0.15
32 x 1''	40	43	127	88	0.21
40 x 1''	40	52	141	94	0.26
40 x 1¼''	48	52	149	99	0.31
50 x 1¼''	55	62	166	108	0.43
63 x 2''	67	80	196	127	0.70
75 x 2½"	83	95	226	162	1.15
90 x 3''	96	112	260	180	1.79
110 x 4''	122	135	296	203	2.60
125 x 4''	122	151	312	225	3.14
