• PE100-RC material is resistant to the long-term expansion of cracks, scratching, and point-type loads. Point-type loads are especially common during the assembly of the pipelines using trenchless installation methods (for instance, as a result of friction against the stones that are present in the soil). In the case of a point-type load, tension, and plastic deformations are produced in the material, which may cause cracks in the internal surface.
• The result of applying electrofusion fittings is a solid and safe joint of pipe and any other elements belonging to the pipeline system. The electrofusion joint features excellent pressure resistance and tightness.

Electrofusion elbows are used in installations distributing gas and water.

• Material: Polyethylene PE100-RC
• SDR class: 11
• MRS: 10 [MPa]
• Work pressure water systems: 16 [bar]
• Work pressure gas systems: 10 [bar]

Product dimensions
D1 [mm]	A [mm]	D3 [mm]	Weight [kg]
180	412	213	7.00
200	448	238	11.04
225	496	266	12.80
250	643	295	17.80
280	725	336	26.40
315	791	379	35.00
355	893	425	69.80
400	1370	476	95.50
450	1074	537	139.00
500	1199	600	145.00
