• PE100-RC material is resistant to the long-term expansion of cracks, scratching, and point-type loads. Point-type loads are especially common during the assembly of the pipelines using trenchless installation methods (for instance, as a result of friction against the stones that are present in the soil). In the case of a point-type load, tension, and plastic deformations are produced in the material, which may cause cracks in the internal surface.
• The result of applying electrofusion fittings is a solid and safe joint of pipe and any other elements belonging to the pipeline system. The electrofusion joint features excellent pressure resistance and tightness.

Branch saddles are used in installations distributing gas and water.

• Material: Polyethylene PE100-RC
• SDR class: 11
• MRS: 10 [MPa]
• Work pressure water systems: 16 [bar]
• Work pressure gas systems: 10 [bar]

Product dimensions
D1 [mm]	D2 [mm]	A [mm]	L1 [mm]	Weight [kg]
315	225	370	200	6,46
355	225	370	200	6,46
400	225	370	200	7,48
450	225	370	200	6,46
500	225	370	200	6,46
560	225	370	200	6,46
630	225	370	200	7,25
710	225	370	200	6,65
800	225	374	200	7,52
900	225	374	200	7,52
1000	225	374	200	7,52

More sizes available on request
