RIGID MULTI PP UV10
Unperforated drainage discharge pipe, DIN 4262-1
SN8 (kN/m²), DN/OD 110, 160, 200 mm
RIGID MULTI PP UV10 are rigid smooth-wall drainage discharge pipes from UV-stabilized polypropylene (PP) material. According to product standard DIN 4262-1 they are type R3 pipes- with smooth wall structure.
- Standard pipe bar length: 6 [m]
- Nominal ring stiffness class: SN8 [kN/m²]
- Available sizes: DN/OD 110, 160 un 200 [mm]
- UP type- unperforated liquid transportation pipe
-
Advantages
Good balance between product ring stiffness, ring flexibility and impact resistance
Ability to withstand overall sun radiation UV exposure > 700 Kly
Products are resistant to exposure to aggressive substances present in sewage and subsoil from pH2 (acidic medium) until pH12 (alkaline medium)
The products are environment-friendly and recyclable after several decades in operation
Long operational life - overs 50 years
-
Recommended application
Field drainage
RIGID MULTI PP UV10 can be constructed as part of a drainage piping system - in places where it is necessary to create discharge outlet. The specially modified polypropylene material provides UV protection against solar radiation for a period of at least 10 years (UV radiation >700 kLy).
For drainage on plots where the depth of groundwater deposition is less than the drainage norm, i.e. land plots for which, due to high groundwater levels, the topsoil is unable to drain excess moisture in the spring period, as well as due to high groundwater levels, underground engineering structures, roads, etc. are damaged.
-
Technical information
RIGID MULTI UV10 pipe is equipped with SEAL LOCK socket and integrated sealing ring². The supplied sealing ring grants a hermetic seal with a pressure rating of ≥0,5 [bar] for the coupling area.
- Material: UV-stabilized polypropylene (PP)
- Produced according to DIN 4262-1, EN 13476-2
- Ring stiffness: SN8 [kN/m²]
- Ring flexibility RF30
- Impact resistance determined at -10°C (ice crystal)
- Ability to withstand overall sun radiation UV exposure > 700 [Kly]
- Available sizes: DN/OD 110, 160, 200 [mm]
- Standard pipe bar length¹: 6 [m]
¹ Other lengths are available on request
² The sealing ring is resistant to oil according to the requirements of EN 681-2 p.5.10. Compliance is determined by the "Volume change in oil" test according to ISO 1817.
-
